R910995364 Rexroth A A6VM250HD2G/63W1-VZB020 Hydraulic motor genuine For Construction Machinery

R910995364

Notes on the selection of the hydraulic fluid

Variation: Constant pressure control (HD.D) The constant pressure control is superimposed on the HD function. Should system pressure rise as a result of the load torque or reduction of the motor swivel angle, when the setting of the constant pressure control is reached the motor is swivelled out to a higher angle. As a result of the increased displacement and consequent pressure reduction, the control deviation is eliminated. By increasing the displacement the motor produces a higher torque at a constant pressure.

Setting range of constant pressure control valve: sizes 28...200 _________ 80 - 400 bar sizes 250...1000________ 80 - 350 bar

Viscosity limits The limiting values for viscosity are as follows: Sizes 28...200 νmin = 5 mm2 /s, short term at a max. permissible temperature tmax = 115°C νmax= 1600 mm2 /s, short term on cold start (tmin = -40°C) Sizes 250...1000 νmin = 10 mm2 /s, short term at a max. permissible leakage oil temperature tmax = 90°C νmax= 1000 mm2 /s, short term on cold start (tmin = -25°C)

Type Ident-No.

A6VM28DA1/63W-VZB020B 9604014

A6VM28DA2/63W-VZB020B 9604015

A6VM28EP1/63W-VZB020B 9604063

A6VM28EZ1/63W-VZB020B 9604250

A6VM28HA1/63W-VZB020A 9604219

A6VM28HA1R2/63W-VZB020A 2036653

A6VM28HA1U2/63W-VZB020A 9604665

A6VM28HD1/63W-VZB020B 9603912

A6VM28HZ1/63W-VZB020B 9604249

A6VM55DA1/63W-VZB020B 9604017

A6VM55DA2/63W-VZB020B 9604018

A6VM55EP1/63W-VZB020B 9604065

A6VM55EZ3/63W-VZB020B 9604523

A6VM55HA1/63W-VZB020A 9604223

A6VM55HA1R2/63W-VZB020A 2036655

A6VM55HA1U2/63W-VZB020A 9605637

A6VM55HD1/63W-VZB020B 9603911

A6VM55HZ3/63W-VZB020B 9604517

A6VM80DA1/63W-VZB020B 9604020

A6VM80DA2/63W-VZB020B 9604021

A6VM80EP1/63W-VZB020B 9604067

A6VM80EZ3/63W-VZB020B 9604522

A6VM80HA1/63W-VZB020A 9604227

A6VM80HA1R2/63W-VZB020A 9610911

A6VM80HA1U2/63W-VZB020A 9605641

A6VM80HD1/63W-VZB020B 9603720

A6VM80HZ3/63W-VZB020B 9604516

A6VM107DA1/63W-VZB020B 9604023

A6VM107DA2/63W-VZB020B 9604024

A6VM107EP1/63W-VZB020B 9604069

A6VM107EZ3/63W-VZB020B 9604521

A6VM107EZ4/63W-VZB020B 9611133

A6VM107HA1/63W-VZB020A 9604231

A6VM107HA1R2/63W-VZB020A 2011699

A6VM107HA1U2/63W-VZB020A 9605644

A6VM107HD1/63W-VZB020B 9603804

A6VM107HZ3/63W-VZB020B 9604515

A6VM140DA1/63W-VZB020B 9603559

A6VM140DA3/63W-VZB020B 9610778

A6VM140EP2/63W-VZB020B 9605666

A6VM140EZ2/63W-VZB020B 9610772

A6VM140HA1/63W-VZB020A 9610774

A6VM140HA1R2/63W-VZB020A 9610776

A6VM140HA1U2/63W-VZB020A 9605670

A6VM140HD1/63W-VZB020B 9605664

A6VM140HZ1/63W-VZB020B 9605648

A6VM160DA1/63W-VZB020B 9604026

A6VM160DA3/63W-VZB020B 9604794

A6VM160EP2/63W-VZB020B 9604072

A6VM160EZ2/63W-VZB020B 9604254

A6VM160HA1/63W-VZB020A 9604235

A6VM160HA1R2/63W-VZB020A 2036656

A6VM160HA1U2/63W-VZB020A 9604666

A6VM160HD1/63W-VZB020B 9603805

A6VM160HZ1/63W-VZB020B 9604252

A6VM200DA1/63W-VAB020B 9604029

A6VM200DA3/63W-VAB020B 9610785

A6VM200EP2/63W-VAB020B 9604074

A6VM200EZ2/63W-VAB020B 9604257

A6VM200HA1/63W-VAB020A 9604239

A6VM200HA1R2/63W-VAB020A 9610792

A6VM200HA1U2/63W-VAB020A 9604667

A6VM200HD1/63W-VAB020B 9603913

A6VM200HZ1/63W-VAB020B 9604255

A6VM250EP2D/63W2-VZB020B 978 736

A6VM250HD2D/63W1-VZB020B 983 132

A6VM250HZ/63W2-VZB027B 999 277
