Product Details
Place of Origin: China
Brand Name: REXROTH
Model Number: A4FO22 A4FO28 A4FO71 A4FO125 A4FO180 A4FO250
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: NIGOTIATION
Packaging Details: standard box
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 1000/month
Usage: |
Oil,Hydraulic Piston Pump |
Appliion: |
Metering,Other |
Structure: |
Piston Pump |
Power: |
Hydraulic |
Pressure: |
High Pressure |
Fuel: |
Hydraulic |
Theory: |
Hydraulic Pumps |
Standard Or Nonstandard: |
Standard |
Color: |
Black Or As You Need |
Material: |
Cast Iron |
Product Name: |
Hydraulic Pumps,Genuine Rexroth Hydraulic Gear Pump |
Feature: |
High Efficiency,Long Life |
Type: |
Hydraulic Pump Rexroth |
Name: |
Rexroth Piston Pump |
Origin: |
China |
Usage: |
Oil,Hydraulic Piston Pump |
Appliion: |
Metering,Other |
Structure: |
Piston Pump |
Power: |
Hydraulic |
Pressure: |
High Pressure |
Fuel: |
Hydraulic |
Theory: |
Hydraulic Pumps |
Standard Or Nonstandard: |
Standard |
Color: |
Black Or As You Need |
Material: |
Cast Iron |
Product Name: |
Hydraulic Pumps,Genuine Rexroth Hydraulic Gear Pump |
Feature: |
High Efficiency,Long Life |
Type: |
Hydraulic Pump Rexroth |
Name: |
Rexroth Piston Pump |
Origin: |
China |
Features
▶ Fixed pump in axial piston swashplate design for hydrostatic drives in an open circuit
▶ For use in mobile and stationary applications
▶ Flow is proportional to the drive speed and displacement.
▶ High power density
▶ High total efficiency
▶ Optimized dimensions for special installation situations
▶ Excellent suction characteristics
▶ Low noise level
▶ Long service life
▶ Economical design
▶ Through drive for combining additional pumps
|
Our product range
|
Hydraulic pump parts
|
|
|
Hydraulic pump parts
|
Cylinder block
|
Press pin
|
|
Piston motor
|
Piston shoe
|
Snap ring
|
|
Piston pump
|
Retainer plate
|
Coil spring
|
|
Gear pump
|
Ball guide
|
Disk spring
|
|
Charge pump
|
Valve plate
|
Barrel washer
|
|
Pilot pump
|
Shoe plate
|
Oil seal
|
|
Vane pump
|
Bearing plate
|
Frication plate
|
|
Repair OEM parts
|
Swash plate
|
Steel plate
|
|
Motor spare parts
|
Drive shaft
|
Metal
|
Rexroth A4FO of A4FO40,A4FO71,A4FO125,A4FO180,A4FO250,A4FO500 hydraulic axial piston pump
1. For hydraulic drive in open circuit
2. Swashplate, fixed displacement piston pump
3. Completely interchangeable with original
4. Flow of pump is proportional to speed and displacement
5. Rated working pressure up to 35Mpa
6. Excellent suction characteristics
7. Fit with long life and high precision bearing
8. Compact structure, light weight and low noise
9. Hydrostatic shoe gurantee long service life
10. Widely applied to the field of construction machinery, such as concrete pump truck, crane, excavator, loader, cement mixer etc.
11. Very competitive price
12. 1 year of warranty
| Size | 22 | 28 | 71 | 125 | 180 | 250 | 500 | 250 | 500 | |||
| Version | Standard | High speed | ||||||||||
| Displacement geometric, per revolution |
Vg | cm³ | 22 | 28 | 71 | 125 | 180 | 250 | 500 | 250 | 500 | |
| Nominal pressure | pnom | bar | 400 | 400 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | |
| Maximum pressure | pmax | bar | 450 | 450 | 400 | 400 | 450 | 400 | 400 | 400 | 400 | |
| Maximum speed 1) | nnom | rpm | 3600 | 3000 | 2200 | 1800 | 1800 | 1500 | 1320 | 1900 | 1500 | |
| Flow | at nnom | qV | l/min | 79 | 84 | 156 | 225 | 324 | 375 | 660 | 475 | 750 |
| Power | at nnom and pnom | P | kW | 53 | 56 | 91 | 131 | 189 | 219 | 385 | 277 | 438 |
| Torque | at pnom | M | Nm | 140 | 178 | 396 | 696 | 1003 | 1393 | 2785 | 1393 | 2785 |
| Weight (approx.) | m | kg | 13.5 | 13.5 | 34 | 61 | 76 | 120 | 220 | 120 | 220 | |
R902426845 A A4FO71/10L-PPB25N00
R902428880 A A4FO71/10L-PZB25N00
R902448477 A A4FO71/10L-VPB25N00
R902425817 A A4FO71/10R-PPB25C09
R902433176 A A4FO71/10R-PPB25K31
R902425821 A A4FO71/10R-PPB25K57
R902419199 A A4FO71/10R-PPB25N00
R902438486 A A4FO71/10R-PZB25K33
R902426161 A A4FO71/10R-PZB25N00
R902425394 A A4FO71/10R-VPB25K33
R902426064 A A4FO71/10R-VPB25N00
R902425392 A A4FO71/10R-VZB25N00
R910994300 A A4FO71/10X-PPB25C03
R910963936 A A4FO71/10X-PPB25C09
R910987978 A A4FO71/10X-PPB25K26
R910969920 A A4FO71/10X-PPB25K33
R910963932 A A4FO71/10X-PPB25K57
R910920898 A A4FO71/10X-PPB25N00
R910927206 A A4FO71/10X-PZB25K25
R910937745 A A4FO71/10X-PZB25K26
R910970037 A A4FO71/10X-PZB25K33
R910921288 A A4FO71/10X-PZB25N00
R910983105 A A4FO71/10X-PZB25N00-SO456
R902403971 A A4FO71/10X-VPB25K33
R910925728 A A4FO71/10X-VPB25N00
R910923423 A A4FO71/10X-VZB25N00
R902419396 A A4FO125/30L-PPB25N00
R902418008 A A4FO125/30L-PZB25N00
R902434690 A A4FO125/30R-FZB25K04
R902413046 A A4FO125/30R-PPB25K24
R902416428 A A4FO125/30R-PPB25K34
R902420734 A A4FO125/30R-PPB25N00
R902416433 A A4FO125/30R-PZB25N00
R902410708 A A4FO250/30L-PPB25N00
R902433990 A A4FO250/30R-PPB25K34
R902413431 A A4FO250/30R-PPB25K35
R902409010 A A4FO250/30R-PPB25N00
R902452732 A A4FO250/30R-PZB25K35
R902407892 A A4FO250/30R-PZB25KB2
R902405596 A A4FO250/30R-PZB25N00
R902422014 A A4FO250/30R-VPB25K02
R910999372 A A4FO250/30R-VPB25N00
R902419400 A A4FO500/30L-PPH25N00
R902422858 A A4FO500/30L-PPH25N00-SO527
R902415137 A A4FO500/30R-PPH25N00
R902425505 A A4FO500/30R-PZH25K43
R902425502 A A4FO500/30R-PZH25N00
R902455676 A A4FO500/30R-VPH25N00
R902559853 A A4FO500/30R-VZH25K43
R902245552 A4FO16/32R-NSC12N00
R902071119 A4FO22/32+ A4FO16/32
R902049850 A4FO22/32L-NSC12K01
R902228110 A4FO22/32L-NSC12K01
R902071109 A4FO22/32L-NSC12K02
R902237310 A4FO22/32L-NSC12K02
R902071332 A4FO22/32L-NSC12N00
R902208886 A4FO22/32L-NSC12N00
R902035996 A4FO22/32R-NSC12K01
R902043328 A4FO22/32R-NSC12K01
R992001247 A4FO22/32R-NSC12K01
R902228112 A4FO22/32R-NSC12K01
R902248099 A4FO22/32R-NSC12K01
R902035997 A4FO22/32R-NSC12K02
R902255911 A4FO22/32R-NSC12K02
R902237309 A4FO22/32R-NSC12K02
R902035995 A4FO22/32R-NSC12N00
R902433735 A4FO250/30R+ A4FO125/30R
R902089163 A4FO28/32+ A4FO28/32
R902071212 A4FO28/32L
R902049900 A4FO28/32L-NSC12K01
R902035990 A4FO28/32L-NSC12K01
R902239965 A4FO28/32L-NSC12K01
R902071164 A4FO28/32L-NSC12K02
R902253845 A4FO28/32L-NSC12KXX-S
R902208887 A4FO28/32L-NSC12KXX-S
R902077904 A4FO28/32L-NSC12N00
R902208964 A4FO28/32L-NSC12N00
R902228116 A4FO28/32L-NSC12N00
R902231070 A4FO28/32L-NSC12N00
R902035993 A4FO28/32L-NSC12N00-S
R902035989 A4FO28/32R-NSC12K01
R902043182 A4FO28/32R-NSC12K01
R902043135 A4FO28/32R-NSC12K01
R902239964 A4FO28/32R-NSC12K01
R902035992 A4FO28/32R-NSC12K01-S
R902035994 A4FO28/32R-NSC12K02
R902228114 A4FO28/32R-NSC12K02
R902239748 A4FO28/32R-NSC12K02
R902035991 A4FO28/32R-NSC12N00
R902228115 A4FO28/32R-NSC12N00
R902229021 A4FO28/32R-NSC12N00
R902071086 A4FO28/32R-NTC12K02
R902088078 A4FO40/32+ A4FO28/32
R902444067 AE A4FO71/10R-PPB25N00
R902422096 AE A4FO125/30R-PPB25N00
R910992937 AE A4FO250/30R-KPB13N00
R902423149 AE A4FO250/30R-PPB25K02
R902448613 AE A4FO250/30R-PPB25N00
R902451737 AE A4FO250/30R-VPB25N00
R902558147 AH A4FO250/30L-PPB25N00
R902412100 AH A4FO250/30R-PPB25N00
R902433984 AH A4FO500/30R-PZH25N00
R902426145 AH A4FO500/30R-PPH25N00
R902439456 AH A4FO500/30R-PZH25K34
R902446140 AL A4FO125/30R-PPB25N00
R902431603 AL A4FO250/30L-PPB25N00
R902437217 AL A4FO500/30R-PPH25N00
