BETTER PARTS Machinery Co., Ltd. bbonniee@163.com 86--13535077468
Product Details
Place of Origin: China
Brand Name: Rexroth
Model Number: 4WRTE
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: NIGOTIATION
Packaging Details: standard box
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 1000/month
Usage: |
Oil,Hydraulic Piston Pump |
Appliion: |
Hydraulic System,hydraulic Pumps,exvaor |
Structure: |
Piston Pump,Hydraulic Pumps |
Power: |
Hydraulic |
Pressure: |
High Pressure,Other |
Fuel: |
Hydraulic,oil |
Theory: |
Rotary Pump,Axial Flow Pump,hydraulic Pumps |
Standard Or Nonstandard: |
Standard |
Color: |
Black,Customer's Request |
Material: |
Cast Iron,Cast/Steel/Bronze/Ductile Iron And So On |
Product Name: |
Hydraulic Pumps,Genuine Rexroth Hydraulic Gear Pump |
Warranty: |
1 Year |
Condition: |
100%new,New Rexroth Pump,OEM New & Original,Oringal New |
Feature: |
High Efficiency,Long Life |
Type: |
Hydraulic Pump Rexroth |
Name: |
Rexroth Piston Pump,excavator Pump Parts Rexroth Pump Hydraulic Pumps |
Origin: |
China |
Usage: |
Oil,Hydraulic Piston Pump |
Appliion: |
Hydraulic System,hydraulic Pumps,exvaor |
Structure: |
Piston Pump,Hydraulic Pumps |
Power: |
Hydraulic |
Pressure: |
High Pressure,Other |
Fuel: |
Hydraulic,oil |
Theory: |
Rotary Pump,Axial Flow Pump,hydraulic Pumps |
Standard Or Nonstandard: |
Standard |
Color: |
Black,Customer's Request |
Material: |
Cast Iron,Cast/Steel/Bronze/Ductile Iron And So On |
Product Name: |
Hydraulic Pumps,Genuine Rexroth Hydraulic Gear Pump |
Warranty: |
1 Year |
Condition: |
100%new,New Rexroth Pump,OEM New & Original,Oringal New |
Feature: |
High Efficiency,Long Life |
Type: |
Hydraulic Pump Rexroth |
Name: |
Rexroth Piston Pump,excavator Pump Parts Rexroth Pump Hydraulic Pumps |
Origin: |
China |
Rexroth High-response directional valves, pilot operated, with electrical position feedbackand integrated electronics (OBE) 4WRTE
Size 10 … 35
Component series 4X
Maximum operating pressure 350 bar
Maximum flow 3000 l/min
Nominal flow 25 … 1000 l/min
| Type | 4WRTE | ||||||
| Size | 10 | 16 | 25 | 27 | 32 | 35 | |
| Component series | 4X | ||||||
| Installation position | any, preferably horizontal | ||||||
| Earth | kg | 8.7 | 11.2 | 16.8 | 17 | 31.5 | 34 |
| Ambient temperature range | °C | -20 … +50 | |||||
| Sine test according to DIN EN 60068-2-6 | 10 ... 2000 Hz / maximum 10 g / 10 cycles / 3 axes | ||||||
| Noise test according to DIN EN 60068-2-64 | 20 ... 2000 Hz / 10 gRMS / 30 g peak / 30 min / 3 axes | ||||||
| Transport shock according to DIN EN 60068-2-27 | 15 g / 11 ms / 3 shocks / 3 axes | ||||||
| MTTFD values according to EN ISO 13849 1) | Years | 150 | |||||
| Damp heat according to DIN EN 60068-2-30 | Variant 2: +25 °C … +55 °C, 90 % … 97 % relative humidity, 2 cycles á 24 hours | ||||||
| 1) | With symbol E, E1, W6 and W8; in longitudinal control spool direction, there is sufficient positive overlap without shock/vibration load; observe the installation orientation with regard to the main direction of acceleration. |
| Type | 4WRTE | ||||||||
| Size | 10 | 16 | 25 | 27 | 32 | 35 | |||
| Maximum operating pressure | bar | 350 | 270 | 350 | |||||
| Maximum operating pressure | Port P | bar | 350 | 270 | 350 | ||||
| Port A | bar | 350 | 270 | 350 | |||||
| Port B | bar | 350 | 270 | 350 | |||||
| Maximum operating pressure | Pilot control valve | Pilot oil supply 1) | bar | 25 … 315 | |||||
| Maximum return flow pressure | Port T | Internal pilot oil supply | static < 10 bar | ||||||
| Port T | External pilot oil supply | bar | 315 | 250 | 210 | 250 | |||
| Port Y | static < 10 bar | ||||||||
| Nominal flow 2) | l/min | 25 50 100 |
125 150 200 220 |
220 350 |
500 | 400 600 |
1000 | ||
| Maximum flow | l/min | 170 | 460 | 870 | 1000 | 1600 | 3000 | ||
| Pilot flow 3) | l/min | 7 | 14 | 20 | 27 | 29 | |||
| Pilot volume 0 … 100% | cm³ | 1.1 | 2.9 | 6.8 | 17.7 | 33.9 | |||
| Hydraulic fluid temperature range | °C | -20 … +80 | |||||||
| preferably | °C | +40 … +80 | |||||||
| Viscosity range | mm²/s | 20 … 380 | |||||||
| preferably | mm²/s | 30 … 45 | |||||||
| Maximum admissible degree of contamination of the hydraulic fluid, cleanliness class according to ISO 4406 (c) 4) | Class 18/16/13 according to ISO 4406 (c) | ||||||||
| Hysteresis | % | ≤ 0.1 | |||||||
| Response sensitivity | % | ≤ 0.05 | |||||||
| Temperature drift | %/10° C | < 0.3 | |||||||
| 1) | For perfect system behavior, we recommend an external pilot oil supply for pressures above 210 bar. |
| 2) | qV nom ±10% with Δp = 5 bar/control edge; flow for deviating Δp see formula. |
| 3) | At port X or Y with stepped input signal from 0 to 100% (315 bar) |
| 4) | The cleanliness classes specified for the components must be adhered to in hydraulic systems. Effective filtration prevents faults and simultaneously increases the life cycle of the components. For the selection of the filters, see www.boschrexroth.com/filter. |
| Hydraulic fluid | ClassifiSAARion | Suitable sealing materials | Standards | Data sheet | |
| Mineral oils | HL, HLP, HLPD, HVLP, HVLPD | NBR, FKM | DIN 51524 | 90220 | |
| Bio-degradable | Insoluble in water | HETG | NBR, FKM | ISO 15380 | 90221 |
| HEES | FKM | ||||
| Soluble in water | HEPG | FKM | ISO 15380 | ||
| Flame-resistant | Water-free | HFDU, HFDR | FKM | ISO 12922 | 90222 |
| Containing water | HFC (Fuchs Hydrotherm 46M, Petrofer Ultra Safe 620) | NBR | ISO 12922 | 90223 | |
|
Important information on hydraulic fluids: For further information and data on the use of other hydraulic fluids, please refer to the data sheets above or contact us.
▪
There may be limitations regarding the technical valve data (temperature, pressure range, life cycle, maintenance intervals, etc.).
▪
The ignition temperature of the hydraulic fluid used must be 40 K higher than the maximum solenoid surface temperature.
▪
Flame-resistant – containing water:
▪
Maximum operating pressure 210 bar
‐
Maximum pressure differential per control edge 175 bar
‐
Pressure pre-loading at the tank port >20% of the pressure differential, otherwise increased cavitation erosion
‐
Life cycle as compared to operation with mineral oil HL, HLP 50 … 100%
‐
Maximum hydraulic fluid temperature 50 °C
‐
|
|||||
| Type | 4WRTE | ||
| Voltage type | Direct voltage | ||
| Power supply | Nominal voltage | VDC | 24 |
| Lower limit value | VDC | 18 | |
| Upper limit value | VDC | 35 | |
| Maximum admissible residual ripple 1) | Vpp | 2.5 | |
| Maximum current consumption | of the amplifier | A | 1.6 |
| of the amplifier (impulse current) | A | 2.7 | |
| Maximum coil temperature 2) | °C | 150 | |
| Duty cycle | % | 100 | |
| Maximum power consumption | 72 VA (average = 24 VA) | ||
| Required fuse protection | AT | 4 (time-lag) | |
| Protection class according to DIN EN 60529 | IP65 (with mating connector mounted and locked) | ||
| Zero point calibration 3) | % | ≤ 1 | |
| Voltage input "A1" (differential input) | Measurement range | VDC | -10 ... +10 |
| Input resistance | Ω | 100 | |
| Current input "F1" | Input current | mA | 4 ... 20 |
| Input resistance | Ω | 100 | |
| Enable input "A5" | Low level | VDC | 0 ... 2 |
| High level | VDC | > 11 | |
| 1) | Observe the absolute limit values of the supply voltage. |
| 2) | Due to the surface temperatures of the solenoid coils, the standards ISO 13732-1 and ISO 4413 (contact protection) must be observed. |
| 3) | Related to the pressure-signal characteristic curve (symbol V), ex works |
| R900979016 | 4WRTE35E1-1000L-4X/6EG24EK31/A1M |
| R901253763 | 4WRTE35E1-1000L-4X/6EG24EK31/F1V |
| R901187312 | 4WRTE35E1-1000L-4X/6EG24ETK31/A1M |
| R901077004 | 4WRTE35E1-1000L-4X/6EG24K31/A1M |
| R901242220 | 4WRTE35E1-1000L-4X/6EG24K31/A1V |
| R901161014 | 4WRTE35E1-1000L-4X/6EG24K31/A1WB15M |
| R901349455 | 4WRTE35E1-1000L-4X/6EG24K31/F1M |
| R900762387 | 4WRTE35E1000L-4X/6EG24EK31/A1M |
| R900711869 | 4WRTE35E1000L-4X/6EG24ETK31/A1M |
| R900967988 | 4WRTE35E1000L-4X/6EG24K31/A1M |
| R901443247 | 4WRTE35E1000L-4X/6EG24K31/A1WB15M |
| R900757702 | 4WRTE35E1000L-4X/6EG24K31/F1M |
| R901428411 | 4WRTE35E1000P-4X/6EG24K31/A1M |
| R901207448 | 4WRTE35E3-1000L-4X/6EG24K31/A1M |
| R901007740 | 4WRTE35Q2-1000L-4X/6EG24EK31/A1M |
| R901407244 | 4WRTE35Q2-1000L-4X/6EG24ETK31/A5M |
| R900758758 | 4WRTE35Q2-1000L-4X/6EG24K31/A1M |
| R900966092 | 4WRTE35Q2-1000P-4X/6EG24ETK31/A1M |
| R900972121 | 4WRTE35Q2-1000P-4X/6EG24ETK31/A1WB152M |
| R901206645 | 4WRTE35Q2-1000P-4X/6EG24ETK31/A5M |
| R901172061 | 4WRTE35Q2-1000P-4X/6EG24ETK31/A5WB15M |
| R901069542 | 4WRTE35Q2-1000P-4X/6EG24K31/A1WB15M |
| R901021371 | 4WRTE35Q2-1000P-4X/6EG24K31/A5WB15M |
| R900760048 | 4WRTE35Q2-1000P-4X/6EG24TK31/A1M |
| R900729062 | 4WRTE35R1000L-4X/6EG24K31/A1M |
| R900759886 | 4WRTE35R1000L-4X/6EG24K31/A5M |
| R901055281 | 4WRTE35R3-1000L-4X/6EG24ETK31/F1M |
| R901008426 | 4WRTE35V1-1000L-4X/6EG24ETK31/A1M |
| R901026939 | 4WRTE35V1-1000L-4X/6EG24ETK31/A5M |
| R901212804 | 4WRTE35V1-1000L-4X/6EG24ETK31/F1M |
| R900972023 | 4WRTE35V1-1000L-4X/6EG24K31/A1M |
| R901223173 | 4WRTE35V1-1000L-4X/6EG24K31/A1V |
| R900731824 | 4WRTE35V1-1000L-4X/6EG24K31/A5M-280 |
| R900732765 | 4WRTE35V1-1000L-4X/6EG24K31/F1M |
| R901221545 | 4WRTE35V1000L-4X/6EG24EK31/F1M |
| R901309469 | 4WRTE35V1000L-4X/6EG24ETK31/F1M |
| R900974731 | 4WRTE35V1000L-4X/6EG24K31/A1M |
| R900978147 | 4WRTE35V1000L-4X/6EG24K31/A5M |
| R901135021 | 4WRTE35V1000L-4X/6EG24K31/A5WB15M |
| R901204542 | 4WRTE35V1000L-4X/6EG24K31/F1M |
| R901134181 | 4WRTE35V1000P-4X/6EG24ETK31/A1M-280 |
| R901360910 | 4WRTE35V1000P-4X/6EG24K31/A1M |
| R901116120 | 4WRTE35V1000P-4X/6EG24K31/A1M-280 |
| R901294422 | 4WRTE35V1000P-4X=6EG24TK31/A1V-956 |
| R900734707 | 4WRTE35V5-1000P-4X/6EG24TK31/A1M=LB |
| R901111512 | 4WRTE35W6-1000L-4X/6EG24EK31/F1M |
| R900772986 | 4WRTE35W6-1000L-4X/6EG24ETK31/A1M |
| R901369292 | 4WRTE35W6-1000L-4X/6EG24ETK31/F1M |
| R901120543 | 4WRTE35W6-1000L-4X/6EG24K31/A1M |
| R900772870 | 4WRTE35W6-1000L-4X/6EG24K31/A5M |
| R901349456 | 4WRTE35W6-1000L-4X/6EG24K31/F1M |
| R901250171 | 4WRTE35W8-1000L-4X/6EG24EK31/A1M |
| R901251104 | 4WRTE35W8-1000L-4X/6EG24EK31/A1V |
| R901252525 | 4WRTE35W8-1000L-4X/6EG24EK31/F1V |
| R901097373 | 4WRTE35W8-1000L-4X/6EG24ETK31/F1M |
| R901307851 | 4WRTE35W8-1000L-4X/6EG24K31/F1M |
| R901011140 | 4WRTE35W8-1000P-4X/6EG24EK31/F1M |
| R901146839 | 4WRTE35W9-1000L-4X/6EG24K31/A1M |
